Why you may need it?
I am a developer, and I work daily in Integrated Development Environments (IDE), such as Intellij IDEA or Eclipse. These IDEs are desktop applications. Since the advent of Google Documents, I have seen more and more people moving their work from desktop versions of Word or Excel to the cloud using an online equivalent of a word processor or a spreadsheet application.
There are obvious reasons for using a cloud to keep your work. Today, compared to the traditional desktop business applications, some web applications do not have a significant disadvantage in functionalities. The content is available wherever there is a web browser, and these days, that’s almost everywhere. Collaboration and sharing are easier, and losing files is less likely.
Unfortunately, these cloud advantages are not as common in the world of software development as is for business applications. There are some attempts to provide an online IDE, but they are nowhere close to traditional IDEs.
That is a paradox; while we are still bound to our desktop for daily coding, the software is now spawned on multiple servers. Developers needs to work with stuff they cannot keep any more on their computer. Indeed, laptops are no longer increasing their processing power; having more than 16GB of RAM on a laptop is rare and expensive, and newer devices, tablets, for example, have even less.
However, even if it is not yet possible to replace classic desktop applications for software development, it is possible to move your entire development desktop to the cloud. The day I realized it it was no longer necessary to have all my software on my laptop, and noticing the availability of web version of terminals and VNC, I moved everything to the cloud. Eventually, I developed a build kit for creating that environment in an automated way.
In this article I present a set of scripts to build a cloud-based development environment for Scala and big data applications, running with Docker in Amazon AWS, and comprising of a web-accessible desktop with IntelliJ IDE, Spark, Hadoop and Zeppelin as services, and also command line tools like a web based SSH, SBT and Ammonite. The kit is freely available on GitHub, and I describe here the procedure for using it to build your instance. You can build your environment and customize it to your particular needs. It should not take you more than 10 minutes to have it up and running.
What is in the “BigDataDevKit”?
My primary goal in developing the kit was that my development environment should be something I can simply fire up, with all the services and servers I work with, and then destroy them when they are no longer needed. This is especially important when you work on different projects, some of them involving a large number of servers and services, as when you work on big data projects.
My ideal cloud-based environment should:
- Include all the usual development tools, most importantly a graphical IDE.
- Have the servers and services I need at my fingertips.
- Be easy and fast to create from scratch, and expandable to add more services.
- Be entirely accessible using only a web browser.
- Optionally, allow access with specialized clients (VNC client and SSH client).
Leveraging modern cloud infrastructure and software, the power of modern browsers, a widespread availability of broadband, and the invaluable Docker, I created a development environment for Scala and big data development that, for the better, replaced my development laptop.
Currently, I can work at any time, either from a MacBook Pro, a Surface Tablet, or even an iPad (with a keyboard), although admittedly the last option is not ideal. All these devices are merely clients; the desktop and all the servers are in the cloud.
My current environment is built using following online services:
- Amazon Web Services for the servers.
- GitHub for storing the code.
- Dropbox to save files.
In this environment, I currently have:
- A graphical desktop with Intellij idea, accessible via a web browser.
- Web accessible command line tools like SBT and Ammonite.
- Hadoop for storing files and running MapReduce jobs.
- Spark Job Server for scheduled jobs.
- Zeppelin for a web-based notebook.
Most importantly, the web access is fully encrypted with HTTPS, for both web-based VNC and SSH, and there are multiple safeguards to avoid losing data, a concern that is, of course, important when you do not “own” the content on your physical hard disk. Note that getting a copy of all your work on your computer is automatic and very fast. If you lose everything because someone stole your password, you have a copy on your computer anyway, as long as you configured everything correctly.
Using a Web Based Development Environment with AWS and Docker
Now, let’s start describing how the environment works. When I start work in the morning, the first thing is to log into the Amazon Web Services console where I see all my instances. Usually, I have many development instances configured for different projects, and I keep the unused ones turned off to save billing. After all, I can only work on one project at a time. (Well, sometimes I work on two.)
So, I select the instance I want, start it, I wait for a little or go grab a cup of coffee. It’s not so different to turning on your computer. It usually takes a bunch of seconds to have the instance up and running. Once I see the green icon, I open a browser, and I go to a well known URL:
https://msciab.duckdns.org/vnc.html. Note, this is my URL; when you create a kit, you will create your unique URL.
Since AWS assigns a new IP to each machine when you start, I configured a dynamic DNS service, so you can always use the same URL to access your server, even if you stop and restart it. You can even bookmark it in your browser. Furthermore, I use HTTPS, with valid keys to get total protection of my work from sniffers, in case I need to manage passwords and other sensitive data.
Once loaded, the system will welcome you with a Web VNC web client, NoVNC. Simply log in and a desktop appears. I use a minimal desktop, intentionally, just a menu with applications, and my only luxury is a virtual desktop (since I open a lot of windows when I develop). For mail, I still rely on other applications, nowadays mostly other browser tabs.
In the virtual machine, I have what I need to develop big data applications. First and foremost, there is an IDE. In the build, I use the IntelliJ Idea community edition. Also, there is the SBT build tool and a Scala REPL, Ammonite.
The key features of this environment, however, are services deployed as containers in the same virtual machine. In particular, I have:
- Zeppelin, the web notebook for using Scala code on the fly and doing data analysis (
- The Spark Job Server, to execute and deploy spark jobs with a Rest interface (
- An instance of Hadoop for storing and retrieving data from the HDFS (
Note, these URLs are fixed but are accessible within the virtual environment. You can see their web interfaces in the following screenshot.
Each service runs in a separate Docker container. Without becoming too technical, you can think of this as three separate servers inside your virtual machine. The beauty of using Docker is you can add services, and even add two or three virtual machines. Using Amazon containers, you can scale your environment easily.
Last, but not least, you have a web terminal available. Simply access your URL with HTTPS and you will be welcomed with a terminal in a web page.
In the screenshot above you can see I list the containers, which are the three servers plus the desktop. This command line shell gives you access to the virtual machine holding the containers, allowing you to manage them. It’s as if your servers are “in the Matrix” (virtualized within containers), but this shell gives you an escape outside the “Matrix” to manage servers, and desktop. From here, you can restart the containers, access their filesystems and perform other manipulations allowed by Docker. I will not discuss in detail Docker here, but there is a vast amount of documentation on Docker website.
How to setup your instance
Do you like this so far, and you want your instance? It is easy and cheap. You can get it for merely the cost of the virtual machine on Amazon Web Services, plus the storage. The kit in the current configuration requires 4GB of RAM to get all the services running. If you are careful to use the virtual machine only when you need it, and you work, say, 160 hours a month, a virtual machine at current rates will cost 160 x $0.052, or $8 per month. You have to add the cost of storage. I use around 30GB, but everything altogether can be kept under $10.
However, this does bot include the cost of an (eventual) Dropbox (Pro) account, should you want to backup more than 2GB of code. This costs another $15 per month, but it provides important safety for your data. Also, you will need a private repository, either a paid GitHub or another service, such as Bitbucket, which offers free private repositories.
I want to stress that if you use it only when you need it, it is cheaper than a dedicated server. Yes, everything mentioned here can be setup on a physical server, but since I work with big data I need a lot of other AWS services, so I think it is logical to have everything in the same place.
Let’s see how to do the whole setup.
Before starting to build a virtual machine, you need to register with the following four services:
The only one you need your credit card for is Amazon Web Services. DuckDns is entirely free, while DropBox gives you 2GB of free storage, which can be enough for many tasks. Let’s Encrypt is also free, and it is used internally when you build the image to sign your certificate. Besides these, I recommend a repository hosting service too, like GitHub or Bitbucket, if you want to store your code, however, it is not required for the setup.
To start, navigate to the GitHub BigDataDevKit repository.
Scroll the page and copy the script shown in the image in your text editor of choice:
This script is needed to bootstrap the image. You have to change it and provide some values to the parameters. Carefully, change the text within the quotes. Note you cannot use characters like the quote itself, the backslash or the dollar sign in the password, unless you quote them. This problem is relevant only for the password. If you want to play safe, avoid a quote, dollar sign, or backslashes.
PASSWORD parameter is a password you choose to access the virtual machine via a web interface. The
To get the values for
HOST, go to the DuckDNS site and log in. You will need to choose an unused hostname.
Look at the image to see where you have to copy the token and where you have to add your hostname. You must click on the “add domain” button to reserve the hostname.
Configuring your instance
Assuming you have all the parameters and have edited the script, you are ready to launch your instance. Log in to the Amazon Web Services management interface, go to the EC2 Instances panel and click on “Launch Instance”.
In the first screen, you will choose an image. The script is built around the Amazon Linux, and there are no other options available. Select Amazon Linux, the first option in the QuickStart list.
On the second screen, choose the instance type. Given the size of the software running, there are multiple services and you need at least 4GB of memory, so I recommend you select the t2.medium instance. You could trim it down, using the t2.small if you shut down some services, or even the micro if you only want the desktop.
On the third screen, click “Advanced Details” and paste the script you configured in the previous step. I also recommend you enable protection against termination, so that with an accidental termination you won’t lose all your work.
The next step is to configure the storage. The default for an instance is 8GB, which is not enough to contain all the images we will build. I recommend increasing it to 20GB. Also, while it is not needed, I suggest another block device of at least 10GB. The script will mount the second block device as a data folder.You can make a snapshot of its contents, terminate the instance, then recreate it using the snapshot and recovering all the work. Furthermore, a custom block device is not lost when you terminate the instance so have double protection against accidental loss of your data. To increase your safety even further, you can backup your data automatically with Dropbox.
The fifth step is naming the instance. Pick your own. The sixth step offers a way to configure the firewall. By default only SSH is available but we also need HTTPS, so do not forget to add also a rule opening HTTPS. You could open HTTPS to the world, but it’s better if it’s only to your IP to prevent others from accessing your desktop and shell, even though that is still protected with a password.
Once done with this last configuration, you can launch the instance. You will notice that the initialization can take quite a few minutes the first time since the initialization script is running and it will also do some lengthy tasks like generating an HTTPS certificate with Let’s Encrypt.
When you eventually see the management console “running” with a confirmation, and it is no longer “initializing”, you are ready to go.
Assuming all the parameters are correct, you can navigate to
YOURHOST with the hostname you chose, but do not forget it is an HTTPS site, not HTTP, so your connection to the server is encrypted so you must write
https// in the URL. The site will also present a valid certificate for Let’s Encrypt. If there are problems getting the certificate, the initialization script will generate a self-signed certificate. You will still be able to connect with an encrypted connection, but the browser will warn you it is an unknown site, and the connections are insecure. It should not happen, but you never know.
Assuming everything is working, you then access the web terminal, Butterfly. You can log in using the user
app and the password you put in the setup script.
Once logged in, you have a bootstrapped virtual machine, which also includes Docker and other goodies, such as a Nginx Frontend, Git, and the Butterfly Web Terminal. Now, you can complete the setup by building the Docker images for your development environment.
Next, type the following commands:
git clone https://github.com/sciabarra/BigDataDevKit cd BigDataDevKit sh build.sh
The last command will also ask you to type a password for the Desktop access. Once done, it will start to build the images. Note the build will take a about 10 minutes, but you can see what is happening because everything is shown on the screen.
Once the build is complete, you can also install Dropbox with the following command:
The system will show a link you must click to enable Dropbox. You need to log into Dropbox and then you are done. Whatever you put in the Dropbox folder is automatically synced between all your Dropbox instances.
Once done, you can restart the virtual machine, and access your environment at the
You can stop your machine and restart it when you resume work. The access URL stay the same. This way, you will pay only for the time you are using it, plus monthly extra for the used storage.
Preserving your data
The following discussion requires some knowledge of how Docker and Amazon works. If you do not want to understand the details, just keep in mind following simple rule: In the virtual machine, there is an
/app/Dropbox folder available, whatever you place in
/app/Dropbox is preserved, and everything else is disposable and can go away. To improve security further, also store your precious code in a version control system.
Now, if you do want to understand this, read on. If you followed my directions in the virtual machine creation, the virtual machine is protected from termination, so you cannot destroy it accidentally. If you expressly decide to terminate it, the primary volume will be destroyed. All the Docker images will be lost, including all the changes you made.
However, since the folder
/app/Dropbox is mounted as a Docker Volume for containers, it is not part of Docker images. In the virtual machine, the folder
/app is mounted in the Amazon Volume you created, which is also not destroyed even when you expressly terminate the virtual machine. To remove the volume, you have to remove it expressly.
Do not confuse Docker volumes, which are a Docker logical entity, with Amazon Volumes, which is a somewhat physical entity. What happens is that the
/app/Dropbox Docker volume is placed inside the
/app Amazon volume.
The Amazon Volume is not automatically destroyed when you terminate the virtual machine, so whatever is placed in it will be preserved, until you also expressly destroy the volume. Furthermore, whatever you put in the Docker volume is stored outside of the container, so it is not destroyed when the container is destroyed. If you enabled Dropbox, as recommended, all your content is copied to the Dropbox servers, and to your hard disk if you sync Dropbox with your computer(s). Also, it is recommended that the source code be stored in a version control system.
So, if you place your stuff in version control system under the Dropbox folder, to lose your data all of this must happen:
- You expressly terminate your virtual machine.
- You expressly remove the data volume from the virtual machine.
- You expressly remove the data from Dropbox, including the history.
- You expressly remove the data from the version control system.
I hope your data is safe enough.
I keep a virtual machine for each project, and when I finish, I keep the unused virtual machines turned off. Of course, I have all my code on GitHub and backed up in Dropbox. Furthermore, when I stop working on a project, I take a snapshot of the Amazon Web Services block before removing the virtual machine entirely. This way, whenever a project resumes, for example for maintenance, all I need to do is start a new virtual machine using the snapshot. All my data goes back in place, and I can resume working.
First, if you have direct internet access, not mediated by a proxy, you can use native SSH and VNC clients. Direct SSH access is important if you need to copy files in and out of the virtual machine. However, for file sharing, you should consider Dropbox as a simpler alternative.
The VNC web access is invaluable, but sometimes, it can be slower than a native client. You have access to the VNC server on the virtual machine using port 5900. You must expressly open it because it is closed by default. I recommend that you only open it to your IP address, because the internet is full of “robots” that scan the internet looking for services to hook into, and VNC is a frequent target of those robots.
This article explains how you can leverage modern cloud technology to implement an effective development environment. While a machine in the cloud cannot be a complete replacement for your working computer or a laptop, it is good enough for doing development work when it is important to have access to the IDE. In my experience, with current internet connections, it is fast enough to work with.
Being in the cloud, server access and manipulation is faster than having them locally. You can quickly increase (or decrease) memory, fire up another environment, create an image, and so on. You have a datacenter at your fingertips, and when you work with big data projects, well, you need robust services and lots of space. That is what the cloud provides.
