Building a Node.js/TypeScript REST API, Part 1: Express.js

Learn practical TypeScript patterns with interfaces and extended classes. Avoid messy console.log() statements with Winston and the Node.js debug module. Create an Express.js-powered REST API back end from scratch!


Toptalauthors are vetted experts in their fields and write on topics in which they have demonstrated experience. All of our content is peer reviewed and validated by Toptal experts in the same field.

Learn practical TypeScript patterns with interfaces and extended classes. Avoid messy console.log() statements with Winston and the Node.js debug module. Create an Express.js-powered REST API back end from scratch!


Toptalauthors are vetted experts in their fields and write on topics in which they have demonstrated experience. All of our content is peer reviewed and validated by Toptal experts in the same field.
Marcos Henrique da Silva
Verified Expert in Engineering
12 Years of Experience

Marcos has 17+ years in IT and development. His passions include REST architecture, Agile development methodology, and JS.

Share

How Do I Write a REST API in Node.js?

When building a back end for a REST API, Express.js is often the first choice among Node.js frameworks. While it also supports building static HTML and templates, in this series, we’ll focus on back-end development using TypeScript. The resulting REST API will be one that any front-end framework or external back-end service would be able to query.

You’ll need:

  • Basic knowledge of JavaScript and TypeScript
  • Basic knowledge of Node.js
  • Basic knowledge of REST architecture (cf. this section of my previous REST API article if needed)
  • A ready installation of Node.js (preferably version 14+)

In a terminal (or command prompt), we’ll create a folder for the project. From that folder, run npm init. That will create some of the basic Node.js project files we need.

Next, we’ll add the Express.js framework and some helpful libraries:

npm i express debug winston express-winston cors

There are good reasons these libraries are Node.js developer favorites:

  • debug is a module that we will use to avoid calling console.log() while developing our application. This way, we can easily filter debug statements during troubleshooting. They can also be switched off entirely in production instead of having to be removed manually.
  • winstonis responsible for logging requests to our API and the responses (and errors) returned. express-winston integrates directly with Express.js, so that all standard API-related winston logging code is already done.
  • cors is a piece of Express.js middleware that allows us to enable cross-origin resource sharing. Without this, our API would only be usable from front ends being served from the exact same subdomain as our back end.

Our back end uses these packages when it’s running. But we also need to install some development dependencies for our TypeScript configuration. For that, we’ll run:

npm i --save-dev @types/cors @types/express @types/debug source-map-support tslint typescript

These dependencies are required to enable TypeScript for our app’s own code, along with the types used by Express.js and other dependencies. This can save a lot of time when we’re using an IDE like WebStorm or VSCode by allowing us to complete some function methods automatically while coding.

The final dependencies in package.json should be like this:

"dependencies": {
    "debug": "^4.2.0",
    "express": "^4.17.1",
    "express-winston": "^4.0.5",
    "winston": "^3.3.3",
    "cors": "^2.8.5"
},
"devDependencies": {
    "@types/cors": "^2.8.7",
    "@types/debug": "^4.1.5",
    "@types/express": "^4.17.2",
    "source-map-support": "^0.5.16",
    "tslint": "^6.0.0",
    "typescript": "^3.7.5"
}

Now that we have all our required dependencies installed, let’s start to build up our own code!

TypeScript REST API Project Structure

For this tutorial, we are going to create just three files:

  1. ./app.ts
  2. ./common/common.routes.config.ts
  3. ./users/users.routes.config.ts

The idea behind the project structure’s two folders (common and users) is to have individual modules that have their own responsibilities. In this sense, we are eventually going to have some or all of the following for each module:

  • Route configuration to define the requests our API can handle
  • Services for tasks such as connecting to our database models, doing queries, or connecting to external services that are required by the specific request
  • Middleware for running specific request validations before the final controller of a route handles its specifics
  • Models for defining data models matching a given database schema, to facilitate data storage and retrieval
  • Controllers for separating the route configuration from the code that finally (after any middleware) processes a route request, calls the above service functions if necessary, and gives a response to the client

This folder structure provides a basic REST API design, an early starting point for the rest of this tutorial series, and enough to start practicing.

A Common Routes File in TypeScript

In the common folder, let’s create the common.routes.config.ts file to look like the following:

import express from 'express';
export class CommonRoutesConfig {
    app: express.Application;
    name: string;

    constructor(app: express.Application, name: string) {
        this.app = app;
        this.name = name;
    }
    getName() {
        return this.name;
    }
}

The way that we are creating the routes here is optional. But since we are working with TypeScript, our routes scenario is an opportunity to practice using inheritance with the extends keyword, as we’ll see shortly. In this project, all route files have the same behavior: They have a name (which we will use for debugging purposes) and access to the main Express.js Application object.

Now, we can start to create the users route file. At the users folder, let’s create users.routes.config.ts and start to code it like this:

import {CommonRoutesConfig} from '../common/common.routes.config';
import express from 'express';

export class UsersRoutes extends CommonRoutesConfig {
    constructor(app: express.Application) {
        super(app, 'UsersRoutes');
    }
}

Here, we are importing the CommonRoutesConfig class and extending it to our new class, called UsersRoutes. With the constructor, we send the app (the main express.Application object) and the name UsersRoutes to CommonRoutesConfig’s constructor.

This example is quite simple, but when scaling to create several route files, this will help us avoid duplicate code.

Suppose we would want to add new features in this file, such as logging. We could add the necessary field to the CommonRoutesConfig class, and then all the routes that extend CommonRoutesConfig will have access to it.

Using TypeScript Abstract Functions for Similar Functionality Across Classes

What if we would like to have some functionality that is similar between these classes (like configuring the API endpoints), but that needs a different implementation for each class? One option is to use a TypeScript feature called abstraction.

Let’s create a very simple abstract function that the UsersRoutes class (and future routing classes) will inherit from CommonRoutesConfig. Let’s say that we want to force all routes to have a function (so we can call it from our common constructor) named configureRoutes(). That’s where we’ll declare the endpoints of each routing class’ resource.

To do this, we’ll add three quick things to common.routes.config.ts:

  1. The keyword abstract to our class line, to enable abstraction for this class.
  2. A new function declaration at the end of our class, abstract configureRoutes(): express.Application;. This forces any class extending CommonRoutesConfig to provide an implementation matching that signature—if it doesn’t, the TypeScript compiler will throw an error.
  3. A call to this.configureRoutes(); at the end of the constructor, since we can now be sure that this function will exist.

The result:

import express from 'express';
export abstract class CommonRoutesConfig {
    app: express.Application;
    name: string;

    constructor(app: express.Application, name: string) {
        this.app = app;
        this.name = name;
        this.configureRoutes();
    }
    getName() {
        return this.name;
    }
    abstract configureRoutes(): express.Application;
}

With that, any class extending CommonRoutesConfig must have a function called configureRoutes() that returns an express.Application object. That means users.routes.config.ts needs updating:

import {CommonRoutesConfig} from '../common/common.routes.config';
import express from 'express';

export class UsersRoutes extends CommonRoutesConfig {
    constructor(app: express.Application) {
        super(app, 'UsersRoutes');
    }

    configureRoutes() {
        // (we'll add the actual route configuration here next)
        return this.app;
    }

}

As a recap of what we’ve made:

We are first importing the common.routes.config file, then the express module. We then define the UserRoutes class, saying that we want it to extend the CommonRoutesConfig base class, which implies that we promise that it will implement configureRoutes().

To send information along to the CommonRoutesConfig class, we are using the constructor of the class. It expects to receive the express.Application object, which we will describe in greater depth in the next step. With super(), we pass to CommonRoutesConfig’s constructor the application and the name of our routes, which in this scenario is UsersRoutes. (super(), in turn, will call our implementation of configureRoutes().)

Configuring the Express.js Routes of the Users Endpoints

The configureRoutes() function is where we will create the endpoints for users of our REST API. There, we will use the application and its route functionalities from Express.js.

The idea in using the app.route() function is to avoid code duplication, which is easy since we’re creating a REST API with well-defined resources. The main resource for this tutorial is users. We have two cases in this scenario:

  • When the API caller wants to create a new user or list all existing users, the endpoint should initially just have users at the end of the requested path. (We won’t be getting into query filtering, pagination, or other such queries in this article.)
  • When the caller wants to do something specific to a specific user record, the request’s resource path will follow the pattern users/:userId.

The way .route() works in Express.js lets us handle HTTP verbs with some elegant chaining. This is because .get(), .post(), etc., all return the same instance of the IRoute that the first .route() call does. The final configuration will be like this:

configureRoutes() {

    this.app.route(`/users`)
        .get((req: express.Request, res: express.Response) => {
            res.status(200).send(`List of users`);
        })
        .post((req: express.Request, res: express.Response) => {
            res.status(200).send(`Post to users`);
        });

    this.app.route(`/users/:userId`)
        .all((req: express.Request, res: express.Response, next: express.NextFunction) => {
            // this middleware function runs before any request to /users/:userId
            // but it doesn't accomplish anything just yet---
            // it simply passes control to the next applicable function below using next()
            next();
        })
        .get((req: express.Request, res: express.Response) => {
            res.status(200).send(`GET requested for id ${req.params.userId}`);
        })
        .put((req: express.Request, res: express.Response) => {
            res.status(200).send(`PUT requested for id ${req.params.userId}`);
        })
        .patch((req: express.Request, res: express.Response) => {
            res.status(200).send(`PATCH requested for id ${req.params.userId}`);
        })
        .delete((req: express.Request, res: express.Response) => {
            res.status(200).send(`DELETE requested for id ${req.params.userId}`);
        });

    return this.app;
}

The above code lets any REST API client call our users endpoint with a POST or a GET request. Similarly, it lets a client call our /users/:userId endpoint with a GET, PUT, PATCH, or DELETE request.

But for /users/:userId, we’ve also added generic middleware using the all() function, which will be run before any of the get(), put(), patch(), or delete() functions. This function will be beneficial when (later in the series) we create routes that are meant to be accessed only by authenticated users.

You might have noticed that in our .all() function—as with any piece of middleware—we have three types of fields: Request, Response, and NextFunction.

  • The Request is the way Express.js represents the HTTP request to be handled. This type upgrades and extends the native Node.js request type.
  • The Response is likewise how Express.js represents the HTTP response, again extending the native Node.js response type.
  • No less important, the NextFunction serves as a callback function, allowing control to pass through any other middleware functions. Along the way, all middleware will share the same request and response objects before the controller finally sends a response back to the requester.

Our Node.js Entry-point File, app.ts

Now that we have configured some basic route skeletons, we will start configuring the application’s entry point. Let’s create the app.ts file at the root of our project folder and begin it with this code:

import express from 'express';
import * as http from 'http';

import * as winston from 'winston';
import * as expressWinston from 'express-winston';
import cors from 'cors';
import {CommonRoutesConfig} from './common/common.routes.config';
import {UsersRoutes} from './users/users.routes.config';
import debug from 'debug';

Only two of these imports are new at this point in the article:

  • http is a Node.js-native module. It’s required to start our Express.js application.
  • body-parser is middleware that comes with Express.js. It parses the request (in our case, as JSON) before control goes to our own request handlers.

Now that we’ve imported the files, we will start declaring the variables that we want to use:

const app: express.Application = express();
const server: http.Server = http.createServer(app);
const port = 3000;
const routes: Array<CommonRoutesConfig> = [];
const debugLog: debug.IDebugger = debug('app');

The express() function returns the main Express.js application object that we will pass around throughout our code, starting with adding it to the http.Server object. (We will need to start the http.Server after configuring our express.Application.)

We’ll listen on port 3000—which TypeScript will automatically infer is a Number—instead of the standard ports 80 (HTTP) or 443 (HTTPS) because those would typically be used for an app’s front end.

Why Port 3000?

There is no rule that the port should be 3000—if unspecified, an arbitrary port will be assigned—but 3000 is used throughout the documentation examples for both Node.js and Express.js, so we continue the tradition here.

Can Node.js Share Ports With the Front End?

We can still run locally at a custom port, even when we want our back end to respond to requests on standard ports. This would require a reverse proxy to receive requests on port 80 or 443 with a specific domain or a subdomain. It would then redirect them to our internal port 3000.

The routes array will keep track of our routes files for debugging purposes, as we’ll see below.

Finally, debugLog will end up as a function similar to console.log, but better: It’s easier to fine-tune because it’s automatically scoped to whatever we want to call our file/module context. (In this case, we’ve called it “app” when we passed that in a string to the debug() constructor.)

Now, we’re ready to configure all our Express.js middleware modules and the routes of our API:

// here we are adding middleware to parse all incoming requests as JSON
app.use(express.json());

// here we are adding middleware to allow cross-origin requests
app.use(cors());

// here we are preparing the expressWinston logging middleware configuration,
// which will automatically log all HTTP requests handled by Express.js
const loggerOptions: expressWinston.LoggerOptions = {
    transports: [new winston.transports.Console()],
    format: winston.format.combine(
        winston.format.json(),
        winston.format.prettyPrint(),
        winston.format.colorize({ all: true })
    ),
};

if (!process.env.DEBUG) {
    loggerOptions.meta = false; // when not debugging, log requests as one-liners
}

// initialize the logger with the above configuration
app.use(expressWinston.logger(loggerOptions));

// here we are adding the UserRoutes to our array,
// after sending the Express.js application object to have the routes added to our app!
routes.push(new UsersRoutes(app));

// this is a simple route to make sure everything is working properly
const runningMessage = `Server running at http://localhost:${port}`;
app.get('/', (req: express.Request, res: express.Response) => {
    res.status(200).send(runningMessage)
});

The expressWinston.logger hooks into Express.js, automatically logging details—via the same infrastructure as debug—for every completed request. The options we’ve passed to it will neatly format and colorize the corresponding terminal output, with more verbose logging (the default) when we’re in debug mode.

Note that we have to define our routes after we set up expressWinston.logger.

Finally and most importantly:

server.listen(port, () => {
    routes.forEach((route: CommonRoutesConfig) => {
        debugLog(`Routes configured for ${route.getName()}`);
    });
    // our only exception to avoiding console.log(), because we
    // always want to know when the server is done starting up
    console.log(runningMessage);
});

This actually starts our server. Once it’s started, Node.js will run our callback function, which in debug mode reports the names of all the routes we’ve configured—so far, just UsersRoutes. After that, our callback notifies us that our back end is ready to receive requests, even when running in production mode.

Updating package.json to Transpile TypeScript to JavaScript and Run the App

Now that we have our skeleton ready to run, we first need some boilerplate configuration to enable TypeScript transpilation. Let’s add the file tsconfig.json in the project root:

{
  "compilerOptions": {
    "target": "es2016",
    "module": "commonjs",
    "outDir": "./dist",
    "strict": true,
    "esModuleInterop": true,
    "inlineSourceMap": true
  }
}

Then we just need to add the final touches to package.json in the form of the following scripts:

"scripts": {
    "start": "tsc && node --unhandled-rejections=strict ./dist/app.js",
    "debug": "export DEBUG=* && npm run start",
    "test": "echo \"Error: no test specified\" && exit 1"
},

The test script is a placeholder that we’ll replace later in the series.

The tsc in the start script belongs to TypeScript. It’s responsible for transpiling our TypeScript code into JavaScript, which it will output into the dist folder. Then, we just run the built version with node ./dist/app.js.

We pass --unhandled-rejections=strict to Node.js (even with Node.js v16+) because in practice, debugging using a straight “crash and show the stack” approach is more straightforward than fancier logging with an expressWinston.errorLogger object. This is most often true even in production, where letting Node.js continue to run despite an unhandled rejection is likely to leave the server in an unexpected state, allowing further (and more complicated) bugs to occur.

The debug script calls the start script but first defines a DEBUG environment variable. This has the effect of enabling all of our debugLog() statements (plus similar ones from Express.js itself, which uses the same debug module we do) to output useful details to the terminal—details that are (conveniently) otherwise hidden when running the server in production mode with a standard npm start.

Try running npm run debug yourself, and afterward, compare that with npm start to see how the console output changes.

Tip: You can limit the debug output to our app.ts file’s own debugLog() statements using DEBUG=app instead of DEBUG=*. The debug module is generally quite flexible, and this feature is no exception.

Windows users will probably need to change the export to SET since export is how it works on Mac and Linux. If your project needs to support multiple development environments, the cross-env package provides a straightforward solution here.

Testing the Live Express.js Back End

With npm run debug or npm start still going, our REST API will be ready to service requests on port 3000. At this point, we can use cURL, Postman, Insomnia, etc. to test the back end.

Since we’ve only created a skeleton for the users resource, we can simply send requests without a body to see that everything is working as expected. For example:

curl --request GET 'localhost:3000/users/12345'

Our back end should send back the answer GET requested for id 12345.

As for POSTing:

curl --request POST 'localhost:3000/users' \
--data-raw ''

This and all other types of requests that we built skeletons for will look quite similar.

Poised for Rapid Node.js REST API Development with TypeScript

In this article, we started to create a REST API by configuring the project from scratch and diving into the basics of the Express.js framework. Then, we took our first step toward mastering TypeScript by building a pattern with UsersRoutesConfig extending CommonRoutesConfig, a pattern that we will reuse for the next article in this series. We finished by configuring our app.ts entry point to use our new routes and package.json with scripts to build and run our application.

But even the basics of a REST API made with Express.js and TypeScript are fairly involved. In the next part of this series, we focus on creating proper controllers for the users resource and dig into some useful patterns for services, middleware, controllers, and models.

The full project is available on GitHub, and the code as of the end of this article is found in the toptal-article-01 branch.

Understanding the basics

  • Can I use TypeScript with Node.js?

    Absolutely! It’s very common for popular npm packages (including Express.js) to have corresponding TypeScript type definition files. This is true about Node.js itself, plus included subcomponents like its debug package.

  • Yes. Node.js can be used by itself to create production-ready REST APIs, and there are also several popular frameworks like Express.js to reduce the inevitable boilerplate.

  • No, it’s not difficult to start learning TypeScript for those with a modern JavaScript background. It’s even easier for those with experience in object-oriented programming. But mastering all of TypeScript’s nuances and best practices takes time, as with any skill.

  • It depends on the project, but it’s definitely recommended for Node.js programming. It’s a more expressive language for modeling real-world problem domains on the back end. This makes code more readable and reduces the potential for bugs.

  • TypeScript is used anywhere JavaScript is found, but it’s especially well suited to larger applications. It uses JavaScript as a base, adding static typing and much better support for the object-oriented programming (OOP) paradigm. This, in turn, supports a more advanced development and debugging experience.

Hire a Toptal expert on this topic.
Hire Now
Marcos Henrique da Silva

Marcos Henrique da Silva

Verified Expert in Engineering
12 Years of Experience

Lecco, Province of Lecco, Italy

Member since February 25, 2017

About the author

Marcos has 17+ years in IT and development. His passions include REST architecture, Agile development methodology, and JS.

authors are vetted experts in their fields and write on topics in which they have demonstrated experience. All of our content is peer reviewed and validated by Toptal experts in the same field.

World-class articles, delivered weekly.

By entering your email, you are agreeing to our privacy policy.

World-class articles, delivered weekly.

By entering your email, you are agreeing to our privacy policy.

Join the Toptal® community.
